Titan Specialty Airless Guns: Redefining Perfection in Painting

Read Time:4 Minute, 35 Second

To Select The Appropriate Tip For Your Spray Project, Consider The Following Advice: Choose a tip whose aperture size corresponds to the paint or coating you intend to spray. Small spray tips are used for light coatings like lacquers, dyes, and enamels, whereas bigger spray tips are needed for heavy coatings like texture. It is advisable to use a sprayer with paint that has a lower viscosity, or consistency. Use oil-based paint or stain using airless paint sprayers. Paint for an airless sprayer usually doesn’t require thinning. Oil-based paint is used with HVLP paint sprayers. Depending on your choice of paint and tip, airless sprayers can spray anywhere from 1200 to 2500 pounds per square inch (PSI).

Best Size for Perfection in Painting

Choose a tip whose aperture size corresponds to the paint or coating you intend to spray like Titan specialty airless guns. Small spray tips are used for light coatings like lacquers, dyes, and enamels, whereas bigger spray tips are needed for heavy coatings like texture. On the product specification sheet or the container, many paint manufacturers will list the suggested spray tip sizes.

Measure the spray tip following your sprayer’s tip rating. Verify that the sprayer can accommodate the tip you intend to use. Choose a tip size for your sprayer that corresponds with its multiple-gun tip rating if you intend to use multiple spray guns on the job

Pick A Tip: Recognize The Numbers

The majority of spray tips have a three-digit code on them. The width of the fan the tip will produce when sprayed at a distance of 12 inches from the surface is indicated by multiplying the first number by two. The second two figures represent the spray tip’s orifice size in thousandths of an inch, which controls the amount of fluid that exits the tip. A 515 tip, for instance, has an aperture of 15 thousandths of an inch and can spray a fan that is 10 inches wide. The amount of coating that you spray depends on the combination of fan width and orifice size.

As an illustration, consider the orifice size of a 317 and a 517 tip, which are both 17 thousandths of an inch. However, whereas the 317 tip sprays a 6-inch-wide fan, the 517 tip sprays a 10-inch-wide fan. The 517 tip will produce a thinner coating with a lower mil build since the same quantity of paint is exiting the spray tip’s orifice but is spread over a larger fan.

Selecting the Proper Spray Tip

Any spraying job can be significantly impacted by selecting the appropriate tip in terms of final quality, time to completion, and cost-effectiveness. A well-placed tip is a true investment that swiftly pays for itself. For your next paint job, just choose the appropriate spray tip by following our 3-step approach.

Step 1: Determine the thickness of your paint or stain to determine the tip size.
Step 2: Determine the proper tip size by comparing the tip size to the fan width.
Step 3: Verify that the sprayer equipment can accommodate the tip you have chosen.

Worn Tips Expense Money and Time

All spray tips will wear with regular usage, even though sprayer tips are composed of the best quality tungsten carbide, the most abrasion-resistant material available. All coatings contain some amount of abrasive materials, but not all of them. Because of the increase in tip orifice size and decrease in fan breadth that occurs with tip wear, using a worn tip can result in hundreds of dollars worth of wasted paint and effort. This results in higher overspray, more effort, more passes to cover the surface, and significant paint waste.

As much as possible, always reduce the pressure while maintaining a proper spray pattern. In addition to saving paint by minimizing overspray, this also lowers tip wear and extends pump life, which saves you money. For this, you have to search for what is the best titan gun.

Sprayer Tip Design

A spray tip designed especially for your application is available. Knowing your options for airless tips will help you select the Graco spray tip that best suits your requirements. The most adaptable reversible tips available are clean tips, often known as RAC tips. They can be used for a wide range of coatings and come in around 200 sizes. Reversible tips make it simple to remove blockages from tips by simply rotating them 180 degrees to the clean position and then activating the sprayer. Furthermore, the tip guard and housing of RAC tips can be easily replaced without having to be removed because of their unique design.

Conclusion

Titan airless guns provide WideRAC SwitchTips for higher production applications with larger sprayers. They provide a 24-inch fan pattern that is extra-wide, enabling you to spray twice as much area as a typical tip. For these tips to provide a thick enough mil build to cover such a big area in a single pass, a larger orifice size is necessary. The XHD RAC SwitchTips from Titan airless guns are intended for usage with thick coatings that atomize at greater pressures. Their distinctive large gray handle, which makes it simple to rotate even with extremely thick coatings like elastomeric and texturing, helps to identify them. Titan airless guns feature a tip that is precisely developed to complete every spraying application with the greatest professional-grade finish, after years of leading the industry in fluid applications.
